Tunnel construction

Krakbau Spółka Akcyjna specialises in the boring of transport (road and rail) tunnels using mining methods (shooting and mechanical techniques). Construction projects carried out by Krakbau S.A. are based on the NATM (New Austrian Tunnelling Method), which involves combining the anchoring of rock mass with shotcrete made with dry and wet methods. In the case of complex geological conditions (strong water saturation), we bored tunnels using the caisson method. Krakbau S.A. also specialises in refurbishment and retrofit of rail tunnels.

Tunnel Construction

KRAUSEPARKEN, Nordhavn, Denmark

Client: METNORD JV

HOFOR, Copenhagen, Denmark

Client: GAP ENTERPRISE ApS

BORING OF SHAFT, Blessberg, Germany

Client: Ed. Züblin AG

TUNNELWORKS, Trimberg, Germany

Client: Arge Hochtief Infrastructure GmbH, Ed. Züblin AG

CONSTRUCTION OF U3 SUBWAY LINE SECTION, Nuremberg, Germany

Client: ARGE U-BAHN U3 B.1 NÜRNBERG (HOCHTIEF CONSTRUCTION AG I BK INFRASTRUKTUR GMBH) Scope of works: boring and concrete works

TUNEL ALBABSTIEG, Ulm, Germany

Client: ARGE ED. ZÜBLIN AG- MAX BÖGL

TUNEL BAD CANNSTATT S-21, Stuttgart, Germany

Client: ARGE HOCHTIEF INFRASTRUCTURE GMBH, BEMO TUNNELING GMBH I WAYSS UND FREYTAG INGENIEURBAU AG

BUSCHTUNNEL RAIL TUNNEL, Aachen, Germany

Client: HOCHTIEF CONSTRUCTION AG. Scope of works: concrete works in a tunnel, portals, retaining walls outside the tunnel. Tunnel length: 711 m, tunnel cross-section: 70 m²

TUNEL EUERWANG, Nürnberg - Ingolstadt, Germany

Client: ARGE TLM HOCHTIEF CONSTRUCTION AG, ALPINE BAU DEUTSCHLAND AG. Scope of works: boring and concrete works. Tunnel length: 7,700 m, tunnel cross-section at breakout: 149 m²

TUNEL IRLAHÜLL, Nürnberg – Ingolstadt, Germany

Client: ARBEITSGEMEINSCHAFT TUNNEL LOS MITTE – HOCHTIEF CONSTRUCTION AG, ALPINE BAU DEUTSCHLAND GMBH. Scope of works: boring and concrete works. Rail tunnel with a length of 7,260 m, tunnel cross-section at breakout: 149 m². Tunnel radius: 8.80 m at breakout.

TUNEL KÖNIGSHAINER BERGE, Germany

Client: ARGE TUNNEL KÖNIGSHAINER BERGE – HOCHTIEF AG, UNIVERSALE BAU GMBH. Scope of works: boring and concrete works. Road tunnel with a length of approx. 3,300 m. Total volume of concrete placed: >74,000 m³, average thickness of the inside concrete shell: 40 cm.

TUNEL KULCH, Bad Staffelsstein, Germany

Client: ARGE TUNNEL LICHTENFELS (HOCHTIEF SOLUTIONS AG, ALPINE UNTERTAGEBAU GMBH, ALPINE BEMO TUNNELING GMBH, BICKHARDT BAU AG, STUTZ GMBH)

TUNEL RENNSTEIG, Germany

Client: UNIVERSALE BAU GMBH. The longest road tunnel in Germany: 8,000 m. Tunnel cross-section at breakout: approx. 100 m². Scope of works: 3,000 m², volume of rock run: approx. 600,000 m³. Amount of shotcrete: approx. 36,000 m³.

TUNEL SCHLÜCHTERN, Schlüchtern, Germany

Client: ARGE TUNNEL SCHLÜCHTERN (HOCHTIEF AG I ED. ZÜBLIN AG)

TUNEL SIEGKREISEL, Betzdorf, Germany

Client: ARGE TUNNEL SIEGKREISEL (ALPINE BAU DEUTSCHLAND AG I H. KIRCHNER GMBH & CO. KG). Scope of works: boring and concrete works for a road tunnel along B62 national road. Tunnel length: 370 m, tunnel cross-section at breakout: 86 m² - 125 m².

TUNEL SIGAUER, Frankfurt – Cologne, Germany

Client: UNIVERSALE-BAU GESELLSCHAFT GMBH. Rail tunnel with a length of approx. 400 m. 1 tunnel tube with a cross-section of approx. 140 m² at breakout. Total volume of rock run: approx. 56,000 m³. Due to large water inflows, we used the caisson method at a section of approx. 120 m.

TUNEL WALBERG – HOPFENBERG, Hessisch - Lichtenau, Germany

Client: ARGE TUNNEL WALBERG – HOPFENBERG (ED. ZÜBLIN AG I ALPINE BAU DEUTSCHLAND AG). Scope of works: boring works. Road tunnel along A44 motorway from Kassel to Herleshausen. Tunnel length: Walberg tunnel: 280 m, Hopfenberg tunnel: 540 m.

AMAGERVÆRKET SHAFT AND HEATING TUNNEL, Copenhagen, Denmark

Client: KFT-JV KOBENHAVNS FJERNVARME TUNNEL. Scope of works: shaft and tunnel boring.

TUNELE LINII METRA, Nordhavn, Denmark

Client: METNORD JV

Lu - Vianden, Luxembourg

Client: ARGE ERWEITERUNG PSW VIANDEN (ED. ZÜBLIN AG, STRABAG AG, JÄGER BAU GMBH)

Tunel Eva and Odenplan station, Sweden

Client: BILFINGER BERGER CIVIL ODENPLAN AB

Tunel and station Triangeln, Sweden

Client: MCG MALMÖ CITYTUNNEL GROUP HB

Tunel Vasa, Sweden

Client: BILFINGER BERGER CIVIL ODENPLAN AB
